NAUTILUS SAFETY SPECTACLE

PANORAMIC WRAP AROUND LENS WITH NOSE BUDS (NTLS 1090)

Description :

  • Revolutionary safety spectacle showcases the maximum safeguard against eye injuries
  • Extraordinary 9.75 curved lenses provide more than 180 degree of coverage, without the distraction of seams or traditional type side shields.
  • 4 points adjustable temples
  • Semi-frame and slim temple design creates a spectacle that weighs only 27 grams per pc.
  • Special nose-buds secure the glass to your face without slipping, while providing a pillow soft fit
  • High impact resistance and anti-scratch lens
  • Lenses provide 99.9% of UV protection
  • Conforms to ANSI Z87.1-2020, CE EN166 : 2001, AS 1337

Lens Options :

  • Clear, Amber, Smoke, IR5 Infra Red, Green shade 5 lens for gas welders

Packing Details :

  • Quantity : 12 pcs in a box and 12 boxes in a carton (144 pcs in carton)
  • Dimension of carton : 61 cm x 45 cm x 31 cm
  • Weight : Approx 7.4 kg

General Specifications :

  • Lens thickness : 2.2 mm
  • PD : 68 mm
  • Lens base : 9.75 curve
  • Weight : 27 gm
  • Lens size vertical : 45 mm
  • Lens size diagonal : 56 mm
  • Bridge : 10.5 mm
  • Temple length (lens-tip) : 150-163 mm
  • Overall width (hinge-hinge) : 142 mm
  • Closest point between lens : 17 mm
  • Closest point between temple tips : 95-98 mm
Component Material  Features
Lens Polycarbonate Full eye protection
Frame Polycarbonate Lens clip in frame
Side Shields Polycarbonate Integral to lens
Nose Piece Bridge Polycarbonate Integral to frame
Sleeve Nylon 4 length position adjust
Temple Nylon Length adjustable
Hinge Polycarbonate/Nylon 3 Barrel type
Screw Stainless Steel Standard hinge screw

Origin : Taiwan
